Description
| Specification | Details |
|---|---|
| Model | C9200L-48P-4G-E |
| Brand | Cisco |
| Downlinks (10/100/1000 or PoE+ Copper Ports) | 48 Ports Full PoE+ |
| Uplink Configuration | 4 × 1G Fixed Uplinks |
| Default Primary AC Power Supply | PWR-C5-1KWAC |
| Fans | Fixed Redundant |
| Software | Network Essentials |
| Chassis Dimensions (H × W × D) | 1.73 × 17.5 × 11.3 in (4.4 × 44.5 × 28.8 cm) |
| Virtual Networks | 1 |
| Stacking Bandwidth | 80 Gbps |
| Total MAC Addresses | 16,000 |
| Total IPv4 Routes (ARP + Learned) | 11,000 (8,000 Direct Routes, 3,000 Indirect Routes) |
| IPv4 Routing Entries | 3,000 |
| IPv6 Routing Entries | 1,500 |
| Multicast Routing Scale | 1,000 |
| QoS Scale Entries | 1,000 |
| ACL Scale Entries | 1,500 |
| Packet Buffer (per SKU) | 6 MB Buffers for 24- or 48-Port Gigabit Ethernet Models |
| Flexible NetFlow (FNF) Entries | 16,000 Flows on 24- and 48-Port Gigabit Ethernet Models |
| DRAM | 2 GB |
| Flash | 4 GB |
| VLAN IDs | 1024 |
| Total SVIs | 512 |
| Jumbo Frames | 9198 Bytes |
| Wireless Bandwidth per Switch | N/A |
| Switching Capacity | 104 Gbps |
| Forwarding Rate | 154.76 Mpps |
| Mean Time Between Failures (MTBF) | 347,760 hours |
| Weight | 4.8 kg |
