Description
| Cisco WS-C3850-24P-E Specifications | |
|---|---|
| General | |
| Model | WS-C3850-24P-E |
| Enclosure Type | Rack-mountable – 1U |
| Ports | 24 x 10/100/1000 (PoE+) |
| Network Management Interface | • Ethernet management port (RJ-45) • Management console port (RJ-45-to-DB9) |
| Available PoE Power | 435W |
| Performance | |
| Switching Capacity | 92 Gbps |
| Maximum Stacking Number | Up to 9 switches |
| Stack Bandwidth | 480 Gbps |
| Forwarding Performance | 68.4 Mpps |
| Flexible NetFlow Entries | 24,000 flows |
| Maximum VLAN IDs | 1,000 |
| MAC Address Table Size | 32K |
| Hardware | |
| CPU | Multicore CPU |
| RAM | 4 GB |
| Flash Memory | 2 GB |
| Wireless Capabilities | |
| Max APs per Switch/Stack | 100 |
| Max Wireless Clients per Switch/Stack | 2000 |
| Total WLANs per Switch | 64 |
| Wireless Bandwidth | Up to 20 Gbps |
| Supported Aironet AP Series | 3600, 3500, 2600, 1600, 1260, 1140, 1040 |
| Expansion / Connectivity | |
| Console Ports | USB (Type-B), Ethernet (RJ-45) |
| Expansion Slots | 1 network module slot, 1 redundant power slot |
| Network Module Options | • C3850-NM-4-1G (4 × 1G) • C3850-NM-2-10G (2 × 10G or 4 × 1G) |
| Stacking Cables | • STACK-T1-50CM (0.5 m) • STACK-T1-1M (1 m) • STACK-T1-3M (3 m) |
| Stack Power Cables | • CAB-SPWR-30CM • CAB-SPWR-150CM |
| Power Supply | PWR-C1-715WAC |
| Power Device | Redundant plug-in module |
| Power Redundancy | Optional |
| Voltage Range (Auto) | 100–240V |
| Power Consumption | 88.32W (max) |
| Dimensions & Weight | |
| Width | 17.5 in (44.5 cm) |
| Depth | 17.7 in (44.5 cm) |
| Height | 1.75 in (4.45 cm) |
| Weight | 16.3 lb (7.4 kg) |
| Rack Mounting Kit | Optional |
| MTBF | 269,450 hours |
| Software / Licensing | |
| System Software | IOS IP Services |
| EnergyWise License | ENERGY-MGMT, ENERGY-MGT-100-K9 |
| Access Point Licenses | • L-LIC-CT3850-UPG (e-delivery) • L-LIC-CTIOS-1A (AP adder license) • LIC-CT3850-UPG (paper) • LIC-CTIOS-1A (paper) |
| Features | |
| Layer 2 / Layer 3 Features | EEM, RPS Support, Jumbo Frames, VLANs, Voice VLAN, VTPv2, CDPv2, LLDP, LACP, PAgP, PVST/PVST+, STP, PortFast, UplinkFast, DTP, CoS Trust/Override, ACLs, Policing, Auto QoS, Scheduling, Priority Queuing, CoS Queues, Queue Weights, Buffers, IGMP/MLD, DHCP Server, HSRP, VRRP, BGP, EIGRP, OSPF, IS-IS, VRF-lite, PIM-SM/DM, SSM, Flexible NetFlow |
| Advanced Network Security | |
| Security Features | Port Security, DHCP Snooping, DAI, IP Source Guard, uRPF, Private VLAN, BPDU Guard, Root Guard, ACLs, TrustSec SXP, SSH, Kerberos, SNMPv3, RADIUS, TACACS+, IGMP Filtering, Wireless end-to-end security |
| Environmental Ranges | |
| Operating Temp (AC) | 23°F to 113°F (-5°C to 45°C) |
| Operating Temp (DC) | 23°F to 113°F (-5°C to 45°C) |
| Short-term Exception | Up to 131°F (55°C) |
| Storage Temperature | -40°F to 160°F (-40°C to 70°C) |
| Operating Altitude | Up to 13,000 ft (4,000 m) |
| Storage Altitude | Up to 15,000 ft (4,573 m) |
| Operating Humidity | 10%–95% non-condensing |
| Storage Humidity | 10%–95% non-condensing |
