| Cisco AIR-AP1832I-A-K9 Access Point Specification | |
|---|---|
| Model | AIR-AP1832I-A-K9 |
| Brand | Cisco |
| Software | Cisco Unified Wireless Network Software Release with AireOS wireless controllers: 8.1.121.0 or later |
| Deployment Modes | Centralized, standalone, sniffer, Cisco FlexConnect™, monitor, OfficeExtend, mesh |
| Supported Wireless LAN Controllers | Cisco 2500 Series Wireless Controllers, Cisco Wireless Controller Module for ISR G2, nCisco WiSM2 for Catalyst 6500, Cisco 5500/5520, Cisco Flex 7500, Cisco 8500/8540, nCisco 5760, Catalyst 3650/3850 with integrated controller, Cisco Mobility Express |
| 802.11n Features | 3×3 MIMO with 2 spatial streams, MRC, 20/40 MHz channels, up to 300 Mbps (5 GHz), nA-MPDU/A-MSDU Tx/Rx, 802.11 DFS, CSD |
| 802.11ac Wave 1 & 2 Features | 3×3 MIMO, 2 spatial streams, SU/MU-MIMO, MRC, transmit beamforming, n20/40/80 MHz channels, up to 867 Mbps, A-MPDU/A-MSDU Tx/Rx, 802.11 DFS, CSD |
| Integrated Antenna | 2.4 GHz: 3 dBi, omnidirectional, 360° n5 GHz: 5 dBi, omnidirectional, 360° |
| Interfaces | 1× 10/100/1000BASE-T (RJ-45, PoE), RJ-45 console port, USB 2.0 (future support) |
| Indicators | Status LED (boot loader, association, operation, warnings, errors) |
| Dimensions | 8.3 × 8.3 × 2 in. (210.8 × 210.8 × 50.8 mm) |
| Environmental | Non-operating temp: -30°C to 70°C nOperating temp: 0°C to 40°C nNon-operating altitude: up to 15,000 ft nOperating altitude: up to 9,843 ft nHumidity: 10% to 90% non-condensing |
| System Memory | 1 GB DRAM, 256 MB flash |
| Input Power Requirements | 44–57 VDC; power supply/injector: 100–240 VAC, 50–60 Hz |
| Power Draw | 15.4 W (actual PoE draw depends on cable) |
| Powering Options | 802.3af/802.3at, Enhanced PoE, AIR-PWR-C=, AIR-PWRINJ5=, AIR-PWRINJ6= nNote: USB disabled under 802.3af PoE |
