| Model |
C9200L-48PXG-2Y-E |
| Brand |
Cisco |
| Downlinks (10/100/1000 or PoE+) |
48 ports full PoE+ (8 mGig up to 10G, 40 ports up to 1G) |
| Uplink Configuration |
2 × 25G fixed uplinks |
| Default Primary AC Power Supply |
PWR-C5-1KWAC |
| Fans |
Fixed redundant |
| Software |
Network Essentials |
| Chassis Dimensions |
1.73 × 17.5 × 13.8 in (4.4 × 44.5 × 35.0 cm) |
| Virtual Networks |
1 |
| Stacking Bandwidth |
80 Gbps |
| Total Number of MAC Addresses |
16,000 |
| Total Number of IPv4 Routes |
11,000 (8,000 direct + 3,000 indirect) |
| IPv4 Routing Entries |
3,000 |
| IPv6 Routing Entries |
1,500 |
| Multicast Routing Scale |
1,000 |
| QoS Scale Entries |
1,000 |
| ACL Scale Entries |
1,500 |
| Packet Buffer per SKU |
6 MB (24- or 48-port Gigabit Ethernet models) |
| Flexible NetFlow Entries |
16,000 flows (24- and 48-port models) |
| DRAM |
2 GB |
| Flash |
4 GB |
| VLAN IDs |
1,024 |
| Total SVIs |
512 |
| Jumbo Frames |
9,198 bytes |
| Wireless Bandwidth per Switch |
N/A |
| Switching Capacity |
340 Gbps |
| Forwarding Rate |
252.97 Mpps |
| Mean Time Between Failures |
337,260 hours |
