| Model |
C9300L-48T-4G-A |
| Brand |
Cisco |
| Designed to Replace |
Catalyst 3850 |
| Supported IOS |
Network Advantage, Network Essentials |
| Network Module Options |
Fixed Modules |
| Stack Technology |
StackWise-320 |
| Stacking Bandwidth |
320 Gbps |
| Total Number of MAC Addresses |
32,000 |
| Total Number of IPv4 Routes |
32,000 (24,000 direct + 8,000 indirect) |
| IPv6 Routing Entries |
16,000 |
| Multicast Routing Scale |
8,000 |
| QoS Scale Entries |
5,120 |
| ACL Scale Entries |
5,120 |
| Packet Buffer per SKU |
16 MB (24- and 48-port Gigabit Ethernet models) |
| Flexible NetFlow Entries |
64,000 flows (24- and 48-port models) |
| DRAM |
8 GB |
| Flash |
16 GB |
| VLAN IDs |
4,094 |
| Total SVIs |
1,000 |
| Jumbo Frames |
9,198 bytes |
| Switching Capacity |
56 Gbps – 176 Gbps |
| Forwarding Rate |
41.66 Mpps – 130.95 Mpps |
| Weight |
15.41 lbs (7.0 kg) |
