| Category | Specification |
|---|---|
| Brand | Cisco |
| Model | MS390-24UX-HW |
| Total Ports | 24 |
| Port Type | mGig |
| Layer Type | Layer 3 |
| UPOE Support | Yes |
| Switching Capacity | 320 Gbps |
| Forwarding Rate | 238.09 Mpps |
| Power Supply | AC |
| Management | Cloud Managed via Meraki Dashboard |
| Stacking | Supported, up to 8 units |
| Jumbo Frame Support | Yes, up to 9,216 bytes |
| Security Features | 802.1X, RADIUS, ACLs |
| QoS | 8 hardware queues per port |
| MTBF | 262,960 hours |
| VoIP Support | Yes |
| Operating Temperature | 0°C to 45°C |
| Dimensions (W × D × H) | 17.4 × 16.3 × 1.7 inches |
| Warranty | Limited Lifetime |
