| Category | Specification |
|---|---|
| Interfaces | • 48 × 10/100/1000BASE-T RJ45 (auto-negotiation, auto-MDIX) • 4 × SFP+ 10GbE uplinks • 2 × stacking ports |
| Switching Capacity | 176 Gbps |
| Stacking Bandwidth | 80G (dual interface) |
| Available PoE+ Power | 740 W |
| Idle / Full Load Power | 54 W / 882 W |
| Power Supply Configuration | Hot-swappable |
| Supported Power Supply | 2 × 640 W PSU |
| What’s Included | 1 × MA-PWR-640WAC power supply, mounting screw kit |
| Dimensions | 1.72 × 19 × 13.38 in (4.38 × 48.46 × 34 cm) |
| Weight | 9.63 lb (4.37 kg) |
| Forwarding Rate | 127.98 mpps |
| Management | • Managed via Meraki cloud Dashboard • Integrated with Meraki wireless & full portfolio • Zero-touch provisioning • Per-port & per-client stats • DHCP/client/hostname fingerprinting • SNMPd & SYSLOG support • Automatic firmware upgrades |
| Remote Diagnostics | • Email/SMS/push alerts • Cable testing & link failure detection • Live remote packet capture • Interactive network topology • Combined event/config logs |
| Stacking | • Up to 8 switches physical stacking (80 Gbps) • Virtual stacking across thousands of ports |
| Power | • Input: 100–240 VAC, 47–63 Hz • Consumption: 5–1655 W |
| Layer 3 | • Static routing, OSPFv2 • Warm spare (VRRP) • DHCP Relay, DHCP Server |
| Mounting | • 1U rack-mountable • 2-post mounting option • Desktop feet included |
| Ethernet Switching Capabilities | • 802.1p QoS (8 queues) • 802.1Q VLANs (4094) • RSTP/STP (802.1w/802.1D) • Broadcast storm control • LLDP & CDP • 802.3ad link aggregation (up to 8 ports) • Multichassis LAG on stacked switches • Port mirroring • IGMP snooping • MAC table: 32K entries |
| Environment | • Operating temp: -5°C to 50°C • Humidity: 5–95% non-condensing • Variable-speed fans |
| Regulatory | • CSA-US • FCC • IC • CE • RCM • RoHS |
| Security | • 2-factor authentication (Dashboard) • RBAC controls • Password policy enforcement • 802.1X, MAB, hybrid auth • Multi-domain/host auth • Port security (sticky MAC, whitelist) • DHCP snooping, DAI • BPDU guard, root guard, loop guard • IPv4/IPv6 ACLs |
| MTBF Rating | 339,906 hours |
